    What Does Fire Detection Do?

    Fire detection systems that prevent fires that may occur day or night are important for every business. These systems, developed to prevent loss of life and property, are perfect for early intervention. Fire detection systems companies also strengthen the technologies of these products by developing them day by day. If used with automatic fire extinguishing systems, the fire can be extinguished before it starts.

    A fire that can break out suddenly in hospitals, schools, warehouses, workplaces and residences may not always be noticed. Starting with a small spark can lead to bigger problems if left unnoticed for a long time. Thanks to the products they have, fire detection systems companies allow the relevant personnel to be notified easily that a fire has broken out.

    Read More
    Fire control panel – FC723-ZA
    FC723-ZA
    Product Features

    Cerberus PRO Interactive Fire Detection and Alarm Control Panel Modular (2 loops 252 addresses)

    Max 12.loop 756 addresses, Ethernet connection) can be expanded with Synoloop or Cnet card.

    Technicial Specifications
    • Detector compatibility Cerberus PRO FD720 (C-NET)
    • Standard EN 54-2 , EN 54-4
    • Number of addresses 756
    • Number of detector lines ntegrated lines:C-NET loops: 2 With loop extension: 4 Extra lines:C-NET (4 loops per line card): Max. 8 SynoLOOP (4 loops per line card): Max. 8
    • Relay outputs 1x RT alarm, 1x RT fault
    • Supervised output 1x RT alarm , 1x RT fault , 2x Horn
    • Mains voltage AC 98…127 V / AC 196…253 V
    • Operating voltage DC 21…28.6 V
    • Operating current 5000 mA
    • Power supply 150 W
    • Bypass time for emergency power supply 72 h
    • Battery capacity 2 x 12 V, 26 Ah
    • Plug-in position For RS232, RS485 serial ports: 2 , For network modules: 2 , For loop extension: 1
    • Storage temperature -20…+60 °C
    • Relative humidity ≤95 % rel. (no condensation)
    • Protection category IP30
    • Color housing/cover Gray, ~RAL 7035 / Gray, ~RAL 050 00 00
    • Cabinet dimensions (W x H x D) 430 x 796 x 160 mm (without cover cap) 430 x 796 x 188 mm (with cover cap)
